180° In-Line Machine Torch Body.  Arc-Zone Performance Proven™ Replacement for Thermal Dynamics® PWM 4A Plasma Arc Welding Torch.

Note: Pinion Gear Rack Adjustment Option Available. Torch Adjustment Range: 11-1/4" (286mm) Min. to 19" (483mm) Max.


Rated Output DC: 200 Amps 100% Duty Cycle
Tungsten Electrode Capacity 3/16" (4.8mm)
Torch Dimensions Body with Barrel 21" (533mm) Long x 1-3/4" (44mm) Offset from Center Line to Edge of Body
Handle Diameter 1-3/8" (35mm)
BTU/hr 8,000 BTU/hr (2017 kcal/hr)
Coolant  Flow 1/2 gpm @50 psi (1.9 ipm @ 3.7 kg/cm2)

Torch Guides:
Optimize Your Plasma Arc Welding Torch
Plasma Torch Setup Guide
Thermal Arc® Ultima 150
Thermal Arc® Ultima 150 Service Manual
